Foton Diesel Engine Euro II Emmission Standard 2 to 3 ton Cargo Truck/Lorry Truck/Light Truck

1. Applies to transport cargo less than 3 ton;

2. Also be used for small size and short distance transportation.

1. Top brand chassis in China;

2. Spare parts can be supplied all the time;

3. Both gas and diesel can be chosen;

4. Mature model can assure that you use longer time.

1. Emission standard euro2/3/4/5 for exporting with very cheap price;

2. Less fuel but longer distance;

3. Gasoline or diesel engine;

4. Hot sale type can design van cargo size as you required.

Chassis parameters
Chassis model		BJ3045D8JB5-1C	Chassis brand	FOTON
Overall dimensions		4950X1640X2100mm	Wheel base	2600mm
Front/rear wheel track		1320/1240mm	Front/rear suspension	1000/750mm
Approach/departure angle		26/37°	Maximum speed	77km/h
Chassis Manufacturer		BEIQI FOTON MOTOR CO., LTD.
Cab	Configuration	Cab width: 1560mm, single row,allowable 2 passengers, with warm air, Hydraulic brake system
	Color	White,other color is optional
Engine	Model	QC480Q
	Emission	Euro 2
	Type	4 cylinders, in-line, water-cooled , diesel engine
	Rated power	29KW/40hp, rated power speed 3000rpm
	Displacement	1809ml
	Max.torque	104N.m
	Bore x stroke	80X100mm
	Manufacturer	Anhui Quanchai Engine Co.,Ltd
Tire	Size	6.00-13 nylon tire
	Number	6+1 nos
Fuel tank	60L
Rear axle	3.0 tons
Drive form	4X2
Rated voltage	24V,DC
Transmissions	5 speed forward 1 reverse
Steering device	Power assisted steering
Steering wheel	Left hand drive
If there is a slight change in the chassis parameters above, please take the actual product as the standard

Van body structure parameters
Van dimensions	3300X1630X350mm	Loading capacity	3000kg
Van material	metal construction	Color and Logo	Optional
Standard configuration	Chassis,sub frame, Container
Optional configuration	lifting hydraulic cylinder for unloading(Self unloading function)
MOQ, payment terms, delivery terms, price
MOQ	One unit
Payment terms	T/T 30% down payment, 70% balance after inspection before delivery
	L/C is optional
Inspection	Buyer's agent or third party inspection agency,the cost is paid by the buyer
Delivery term	20 days from down payment
Documentation	Maintenance manual
	User manual
	Packing list
	Commercial invoice
	Certificate of origin is optional
	Spare parts list for purchase is optional
Standard tools	With standard tools for chassis and water tank structure
Packing	The main vehicle nude and covered with wax, attached parts and tools put into standard export box
Other requirements	Please fill in here

1, Attached parts and tools put into standard export box.

2, Mini cargo truck will be cleaned and covered with wax before delivery.

3, Mini cargo truck will be covered by waterproof cloth at the departure port.

4, Roll-on/Roll-off ship or bulk cargo ship is optional according to the customers requirements.

5, Some small mini cargo truck can be put into container according to its overall dimensions.

1. Some maintenance spare parts wil be supplied freely when delieverying truck.

2. Main parts, such as engine, axle will be warrantied for 6 months.

3. Spare parts will be supplied at factory cost price, freight will be born by your side.

4. Recordes will be established for each trucks and can supply any parts in future.
