Dongfeng Euro III Standard Diesel Engine 7 to 8 ton Medium Duty Truck/Lorry Truck/Cargo Truck

Dongfeng Euro III Standard Diesel Engine 7 to 8 ton Medium Duty Truck/Lorry Truck/Cargo Truck

1. Applies to transport cargo less than 3 ton;

2. Also be used for various of cargo and long distance transportation.

1. Top brand chassis in China;

2. Spare parts can be supplied all the time;

3. OEM availability, make the truck as per your request;

4. Shortest delievery: 15 to 20days can finish the truck after getting deposit.

1. China top brand powerful engine, start quickly and speed quickly;

2. Wider cabin make you drive comfortabley during long distance transportation;

3. Special double deck for girder steel plate which be sure it can carry more, not easily deform;

4. Power-assisted steering.

Chassis parameters
Chassis model		EQ1090T9ADJ3AC	Chassis brand	DONGFENG
Overall dimensions		6740X2100X2370mm	Wheel base	3800mm
Front/rear wheel track		1740/1610mm	Front/rear suspension	1130/1810mm
Approach/departure angle		20/14°	Maximum speed	103km/h
Chassis Manufacturer		Dongfeng Automobile Co.,Ltd
Cab	Configuration	Cab width: 2025mm, Single row cab, allowable 3 passengers, power-assisted steering, Camel brand battery: 24V/90AH, Pneumatic brake system
	Color	White, other color is optional
Engine	Model	YC4E140-33
	Emission	Euro 3
	Type	4-stroke, water-cooled, turbocharging,diesel engine
	Rated power	105KW/140hp, rated power speed 2800rpm
	Displacement	4257ml
	Bore x stroke	110x112mm
	Manufacturer	Guangxi Yuchai Machinery Group Co.,Ltd
Tire	Size	7.50R16 Steel wire
	Number	6+1 nos
Frame	192mm
Front axle	3.0T
Rear axle	5.5T
Drive form	4X2
Rated voltage	24V,DC
Transmissions	5 speed forward 1 reverse.
Steering wheel	Left hand drive
Selective configuration	Air conditioner
If there is a slight change in the chassis parameters above,please take the actual product as the standard.

Van body structure parameters
Van dimensions	5200X2120X550mm	Loading capacity	8000kg
Van material	Metal construction	Color and Logo	Optional
Standard configuration	Chassis, sub frame, Container
Optional configuration	Lifting hydraulic cylinder for unloading

1, Attached parts and tools put into standard export box.

2, Cargo truck will be cleaned and covered with wax before delivery.

3, Cargo truck will be covered by waterproof cloth at the departure port.

4, Roll-on/Roll-off ship or bulk cargo ship is optional according to the customers requirements.

5, Some small mini cargo truck can be put into container according to its overall dimensions.

1. Some maintenance spare parts wil be supplied freely when delieverying truck.

2. Main parts, such as engine, axle will be warrantied for 6 months.

3. Spare parts will be supplied at factory cost price, freight will be born by your side.

4. Recordes will be established for each trucks and can supply any parts in future.
