Isuzu Euro IV Standard Diesel Engine 6 to 7 ton Dump Truck/Tipper Truck

Isuzu 6 to 7 ton Dump Truck/Tipper Truck

Isuzu Euro IV Standard Diesel Engine 6 to 7 ton Dump Truck/Tipper Truck

● Application of Isuzu 6 to 7 ton Dump Truck/Tipper Truck

1. Applies to transport cargo less than 7 ton.

2. Mainly transport sand, stone, earth and so on.

● Advantages of Isuzu 6 to 7 ton Dump Truck/Tipper Truck

1. Famous world brand chassis;

2. Exceptional fuel efficiency;

3. Lower CO₂ emissions;

4. OEM availablility.

● Features of Isuzu 6 to 7 ton Dump Truck/Tipper Truck

1. Power assisted steering;

2. Isuzu MSB transmission; Isuzu;

3. Turbocharging diesel engine;

4. Euro IV emission standard.

● Details Specification of Isuzu 6 to 7 ton Dump Truck/Tipper Truck

Vehicle parameters
Vehicle Model	HLW51009KARY	Vehicle Brand	ISUZU
Overall dimensions	6500X2250X2570mm	Curb weight	5815kg
Van dimensions	4200X2200X600mm	Loading capacity	7000kg

Chassis parameters
Chassis model		QL11109KARY	Chassis brand	ISUZU
Overall dimensions		6075X2170X2330mm	Wheel base	3815mm
Front/rear wheel track		1680/1650mm	Front/rear suspension	1110/2055mm
Approach/departure angle		21/13°	Maximum speed	110km/h
Chassis Manufacturer		QingLing Motors (Group) Co., Ltd.
Cab	Configuration	700P, single row cab, allowable 3 passengers, air conditioner, cab can be flipped, ABS
	Color	White, other color is optional
Engine	Model	4HK1-TCG40
	Emission	Euro 4
	Type	4 cylinders, 4 valve, 4-stroke, in-line, common rail, precision electronic control, multistage injection, optimal combustion, exhaust gas recirculation, diesel engine.
	Rated power	190hp
	Displacement	5193ml
	Manufacturer	Isuzu Engine (Chongqing) Co., Ltd.
Tire	Size	8.25-16 nylon tire
	Number	6+1 nos
Frame	216X70(6+3)mm
Front axle	4.0 tons
Rear axle	7.0 tons
Drive form	4X2
Suspension	Multi leaf springs
Rated voltage	24V,DC
Transmissions	ISUZU MLD six speed transmission, 6 speed forward 1 reverse.
Steering device	Power assisted steering
Steering wheel	Left hand drive
Selective configuration	Tire: 825R16, 825-20, 825R20, 235/75R17.5
If there is a slight change in the chassis parameters above, please take the actual product as the standard.

Dump truck structure parameters
Van body dimensions	4200X2200X600mm	Side wall	3mm
Bottom plate	4mm	Van body material	Common steel
Lifting position	Middle	Dumping direction	Rear
Oil Cylinder	Domestic Ф110 doulbe	Color and Logo	Optional
Standard configuration	Chassis, sub frame, van body side 3mm bottom 4mm, domestic middle lifting hydraulic cylinder Ф110, common steel, two longitudinal beams, rectangular van body, single door.

MOQ, payment terms, delivery terms, price
MOQ	One unit
Payment terms	T/T 30% down payment, 70% balance after inspection before delivery
	L/C is optional
Inspection	Buyer's agent or third party inspection agency, the cost is paid by the buyer
Delivery term	20 days from down payment
Documentation	Maintenance manual
	User manual
	Packing lis
	Commercial invoice
	Certificate of origin is optional
	Spare parts list for purchase is optional
Standard tools	With standard tools for chassis and van body structure
Packing	The main vehicle nude and covered with wax, attached parts and tools put into standard export box.
Other requirements	Please fill in here

● After-sale service

1, Some maintenance spare parts wil be supplied freely when delieverying truck.

2, Main parts, such as engine, axle will be warrantied for 6 months.

3, Spare parts will be supplied at factory cost price, freight will be born by your side.

4, Recordes will be established for each trucks and can supply any parts in future.

● Packing

1, Attached parts and tools put into standard export box.

2, Cargo truck will be cleaned and covered with wax before delivery.

3, Cargo truck will be covered by waterproof cloth at the departure port.

4, Roll-on/Roll-off ship or bulk cargo ship is optional according to the customers requirements.

5, Some small mini cargo truck can be put into container according to its overall dimensions.
