Isuzu Lorry Truck with 5 tons Knuckle Boom Crane

● Application of Isuzu Lorry Truck with 5 tons Knuckle Boom Crane

1. Truck mounted crane (also called lorry mounted crane, truck mounted boom lift, crane mounted cargo truck, truck with loading crane, boom crane, boom crane truck, articulated crane truck.

2. Used to lift the cargo, load, transport and unload heavy stuff.

● Advantages of Isuzu Lorry Truck with 5 tons Knuckle Boom Crane

1. Famous brand chassis;

2. Spare parts can be supplied all the time;

3. OEM ability, can design porduct as per your request;

4. Isuzu engine with powerful performance.

● Features of Isuzu Lorry Truck with 5 tons Knuckle Boom Crane

1. Wide and high-speed rotary, convenient operation;

2. Unique design, small volume, low noise;

3. Main hydraulic parts are international technology, stable and reliable;

4. Strong lorry truck box.

● Details Specification of Isuzu Lorry Truck with 5 tons Knuckle Boom Crane

Isuzu Lorry Truck With 5 Tons Knuckle Boom Crane

Vehicle Brand

OMC

Chassis Brand

ISUZU

Overall Dimension

9535 * 2465 * 3850 mm

GVW / Kerb Weight

25,000 kg / 11,511 kg

Cab

Cab Capacity

Air Conditioner

Equipped Air conditioner

Engine

Fuel Type

Engine Brand

ISUZU

Power

280 Hp (206 KW)

Displacement

7790 ml

Emission Standard

Euro IV

Chassis

Drive Type

Transmission

9-speed front, 1 reverse

Wheelbase/No. of axle

4650+1300 mm / 3

Tyre Specification

10.00-20

Tyre Number

10 tyres and 1 spare tyre

Max Speed

90 km/h

Paint

Metallic paint

Superstructure

Cargo Box Dimension

Crane Brand

XCMG

Max Lifting Capacity

5000 kg

Lifting Capacity
@ Working Radius

5000 kg @ 2.10 m;  2400kg @ 4.44 m;
1600 kg @ 6.20 m;  1050kg @ 8.01m

Max. Lifting Moment

10.5 T.M

Max. Working Height

10.5 m

Max. Working Radius

8 m

Slewing Angle

360°all rotation

All other standard accessories:

Tool kit, English manual

● Optional

1. Hydraulic tipper box.

2. Box thickness according to requirement.

3. Box height could be nominated.

● Packing

1, Attached parts and tools put into standard export box.

2, Truck mounted crane will be cleaned and covered with wax before delivery.

3, Truck mounted crane will be covered by waterproof cloth at the departure port.

4, Roll-on/Roll-off ship or bulk cargo ship is optional according to the customers requirements.

5, Some small mini cargo truck can be put into container according to its overall dimensions.
