2 Axles 3 Axles 40ft Skeletal Container Chassis Trailer

● Application of 2 Axles 3 Axles 40ft Skeletal Container Chassis Trailer

1. 40ft skeletal trailer mainly transport 40ft ISO container two 20ft ISO standard containers.

2. Mainly used in vessels, ports, routs, highways, transit stations, bridges and multimodel transport system.

● Advantages of 2 Axles 3 Axles 40ft Skeletal Container Chassis Trailer

1. Best quality axle in China;

2. Spare parts can be supplied all the time;

3. OEM availability; can design the truck as per your request;

4. 24 Hours online after-sale service.

● Features of 2 Axles 3 Axles 40ft Skeletal Container Chassis Trailer

1. Exquisite craftsmanship technology. Main parts are processed with advanced equipment;

2. To all the Vehicle parts, we do shot peening;

3. The suspension adopts stamping rigid suspension which is made by independent steel plate and bed made of tandem leaf spring and suspension bearing;

4. The longitudinal beam is welded by automatic tracking submerged arc welding machine.

● Details Specification of 2 Axles 3 Axles 40ft Skeletal Container Chassis Trailer

Product

40ft Skeletal Container Chassis Trailer

Dimensions

12500mm (Length) x 2500mm(Width) x 1640mm (Height)

Tare Weight

6,150 kg

Payload

50,000 kg

G.V.W

56,150 kg

King Pin

8 mm thick steel skidplate with 2.0/3.5 inch bolted type

Landing Gear

JOST, two speed, driver side crank

Cross Members

High strength channel steel

Axles

2 axle or 3 axles, FUWA/BPW/BP brand

Suspensions

Multi-leaf spring suspensions, 10 lines of 90mm*13mm, or 12 lines of 100mm*12mm

Brake System

Dual air brake system, WABCO relay emergency valve.

Brake Chambers

One axle with T30/30 emergency brake chamber, the other two with T30 service brake chamber

Rims

9.0/22.5, 13 units, including a spare one

Tires

11.00R22.5, 13 units, including a spare one

Twist Locks

Twelve retractable ISO standard type twist locks

Electrical

24-Volt sealed wiring harness, 7-pin connector at front

Front Lights

Two front marker lamps, white color

Side Lights

Four side marker lamps per side, amber color

Rear Lights

Standard brake, turn, reverse lights, one license plate lamp, one fog lamp

Reflectors

Conspicuity reflective tapes on bumper and both sides.

Spare wheel carrier

One spare wheel carrier with a spare wheel

Toolbox

1200mm × 500mm × 500mm. Contains hub nut spanner, wheel nut spanner.

● After-sale Service

1. Some maintenance spare parts wil be supplied freely when delieverying truck.

2. Main parts, such as, axle will be warrantied for 6 months.

3. Spare parts will be supplied at factory cost price, freight will be born by your side.

4. Recordes will be established for each trucks and can supply any parts in future.

● Packing

1, Nude Packing 4 sets stacked (by Bulk Cargo Ship, Ro-ro Ship, or Land Transportation).

2, Cut the rear part which can load two sets in one 40ft container.

3, Keep the trailer original but load two sets in one 45ft container.
